Item |
Content |
|
Model |
EPC9505 |
|
Product Type |
125°C Irradiation Cross-Linked Halogen-Free External Insulation Compound |
|
Material Type |
Cross-Linked Halogen-Free Polyolefin / HFFR |
|
Recommended Irradiation Dose |
10–12 MRad |
|
Standard / Grade |
JG/T 411 • 125°C External Insulation Material |
|
Application |
Long-Life Building Wires and Cables Rated 750V and Below |
|
Key Features |
Flame Retardant • Low Smoke Zero Halogen • Cross-Linked • Electrical Insulation |
|
Compliance |
RoHS • REACH • HF • ISO 9001 • IATF 16949 |
Product Overview
EPC9505 is a 125°C irradiation cross-linked halogen-free insulation compound developed as the external insulation layer for long-life building wires and cables rated 750V and below. It is designed to meet the 125°C external insulation material requirements of JG/T 411, combining electron-beam cross-linking with low smoke zero halogen and flame-retardant performance.
As a 125°C LSZH building wire compound, EPC9505 is suitable for the external insulation layer of 750V long-life building cables where flame retardancy, zero-halogen performance and stable mechanical properties after irradiation are required. Its irradiated XLPO structure makes it applicable to halogen-free building wire, low-smoke flame-retardant cable and long-life cross-linked polyolefin insulation constructions.
Key Features
- JG/T 411 125°C External Insulation Material
- Long-Life Building Wire & Cable Application
- 750V and Below Cable Insulation
- Irradiation Cross-Linked HFFR / XLPO
- Halogen Content: 0 PPM
- Oxygen Index: 35%
- Low Smoke Zero Halogen & Flame Retardant
Technical Data Sheet
|
Test Item |
EPC9505 |
Test Method |
|
Density, g/cm³ |
1.53 |
ISO 1183-1 |
|
Melt Index, g/10min |
3.5 |
ISO 1133 (b) |
|
Tensile Strength, MPa |
12.1 |
IEC 60811-1-1 |
|
Elongation at Break, % |
225 |
IEC 60811-1-1 |
|
Aging Test, °C×h |
158×168 |
IEC 60811-1-2 |
|
Tensile Strength after 158°C Aging, MPa |
14.0 |
IEC 60811-1-2 |
|
Elongation after 158°C Aging, % |
200 |
IEC 60811-1-2 |
|
Aging Test, °C×h |
180×168 |
IEC 60811-1-2 |
|
Tensile Strength after 180°C Aging, MPa |
9.7 |
IEC 60811-1-2 |
|
Elongation after 180°C Aging, % |
150 |
IEC 60811-1-2 |
|
Oxygen Index, % |
35 |
ISO 4589-2 |
|
Smoke Density - Flaming |
66 |
ASTM E-662 |
|
Smoke Density - Nonflaming |
198 |
ASTM E-662 |
|
Low-Temperature Impact @ -25°C |
Pass |
IEC 60811-1-4 |
|
Halogen Content, PPM |
0 |
IEC 60754 |
|
pH (min) |
6.0 |
IEC 60754 |
|
Conductivity (max), μS/mm |
1.2 |
IEC 60754 |
|
Volume Resistivity, Ω·m |
1.5×10¹² |
IEC 60093 |
|
Dielectric Strength, MV/m |
25 |
GB/T 1408 |
|
Toxicity Index |
3.5 |
EN 50305 |
|
Hot Set @ 200°C × 15min, % |
40 |
IEC 60811-2-1 |
|
Permanent Deformation, % |
5 |
IEC 60811-2-1 |
Recommended Extrusion Process Temperature
|
Zone |
Zone 1 |
Zone 2 |
Zone 3 |
Zone 4 |
Zone 5 |
Neck |
Head |
Mould |
|
Temperature |
100°C |
110°C |
125°C |
135°C |
150°C |
155°C |
160°C |
165°C |
EPC9505 can be processed on conventional PVC/PE extrusion equipment. A low-compression-ratio screw specifically suitable for LSZH compounds is recommended. Electron-beam irradiation is applied after extrusion to complete cross-linking.
Adjust the extrusion conditions according to cable structure, equipment configuration, screw design and actual melt condition.
For special extrusion equipment, long-life building wire structures or irradiation conditions, please contact our technical team for processing guidance.
Final processing parameters should be confirmed through production trials under the customer's actual extrusion conditions.
OEM & Customization
- Customized Formulations
- OEM Manufacturing
- Color Matching
- Technical Support
- Small Batch
- Fast Sampling
- Free Samples
FAQ
1. What is EPC9505?
EPC9505 is a 125°C irradiation cross-linked halogen-free insulation compound for the external insulation layer of long-life building wires and cables rated 750V and below.
2. Which standard requirement does EPC9505 meet?
EPC9505 is designed to meet the JG/T 411 requirements for 125°C external insulation material.
3. How does EPC9505 differ from XLPE_01?
In the supplied product series, EPC9505 is the 125°C external insulation grade, while XLPE_01 is the 125°C internal insulation grade.
4. Is EPC9505 a low smoke zero halogen flame-retardant material?
The supplied data lists 0 PPM halogen, an oxygen index of 35%, and smoke-density results of 66 by the flaming method and 198 by the nonflaming method.
5. What mechanical properties does EPC9505 provide?
The supplied data lists 12.1 MPa tensile strength and 225% elongation at break.
6. What irradiation dose is recommended?
The recommended irradiation dose is 10–12 MRad.
7. What aging performance is reported?
After 158°C × 168 h aging, tensile strength is 14.0 MPa and elongation is 200%. After 180°C × 168 h aging, tensile strength is 9.7 MPa and elongation is 150%.
8. What is the recommended extrusion temperature profile?
Zone 1: 100°C; Zone 2: 110°C; Zone 3: 125°C; Zone 4: 135°C; Zone 5: 150°C; Neck: 155°C; Head: 160°C; Mould: 165°C.
9. What electrical properties are reported?
The supplied data lists a volume resistivity of 1.5×10¹² Ω·m and dielectric strength of 25 MV/m.
10. Can customized formulations and samples be provided?
Yes. Formulation support, color matching, technical guidance and samples can be provided according to long-life building wire insulation requirements.
