Item |
Content |
|
Model |
EPC6929 |
|
Product Type |
B1-Class Flame-Retardant LSZH Oxygen Barrier Compound |
|
Material Type |
Thermoplastic Low Smoke Zero Halogen Flame-Retardant Polyolefin / HFFR |
|
Application |
Power Cable Oxygen Barrier / Internal Fire-Barrier Layer |
|
Key Performance |
Good Flame Retardancy • Low Heat Release • High Char Formation • LSZH |
|
Processing |
Thermoplastic Extrusion |
|
Halogen Content |
0 PPM |
|
Typical Positioning |
B1-Class Power Cable Oxygen Barrier Material |
Product Overview
EPC6929 is a B1-class flame-retardant low smoke zero halogen oxygen barrier compound developed for power cable constructions. It features good flame-retardant performance, low heat release and a high char-forming rate, making it suitable for cable oxygen-barrier layers that help protect the internal insulation and other cable materials during fire exposure.
As a thermoplastic HFFR fire-barrier material, EPC6929 forms a protective carbonized layer when exposed to heat and flame. It is suitable for LSZH power cables, flame-retardant cable oxygen barriers and zero-halogen fire-protection layers where enhanced charring performance and thermal shielding are required.
Key Features
- Good Flame Retardancy
- Low Heat Release
- High Char-Forming Performance
- B1-Class Cable Application
- LSZH / HFFR Material
- Oxygen Barrier / Fire-Barrier Layer
- Protects Internal Insulation & Cable Components
Technical Data Sheet
|
Test Item |
EPC6929 |
Test Method |
|
Density, g/cm³ |
1.62 |
ISO 1183-1 |
|
Melt Index, g/10min |
3.6 |
ISO 1133 (b) |
|
Tensile Strength, MPa |
8.2 |
IEC 60811-1-1 |
|
Elongation at Break, % |
60 |
IEC 60811-1-1 |
|
Aging Test, °C×h |
100x168 |
IEC 60811-1-2 |
|
Oxygen Index, % |
43 |
ISO 4589-2 |
|
Smoke Density - Flaming |
43 |
ASTM E-662 |
|
Smoke Density - Nonflaming |
187 |
ASTM E-662 |
|
Hardness, Shore A |
95 |
ASTM D2240 |
|
High-Temperature Pressure Test, °C×h |
90x4 |
IEC 60811-3-1 |
|
Halogen Content, PPM |
0 |
IEC 60754 |
|
pH (min) |
6.4 |
IEC 60754 |
|
Conductivity (max), μS/mm |
0.8 |
IEC 60754 |
Recommended Extrusion Process Temperature
|
Zone |
Zone 1 |
Zone 2 |
Zone 3 |
Zone 4 |
Zone 5 |
Neck |
Head |
Mould |
|
Temperature |
100°C |
130°C |
140°C |
145°C |
150°C |
155°C |
160°C |
165°C |
EPC6929 can be processed by thermoplastic extrusion. A low-compression-ratio screw and head are recommended, with a compression ratio of approximately 1:1–1:2. Keep the extrudate temperature below 165°C and do not exceed 175°C.
Adjust the extrusion conditions according to cable structure, equipment configuration, screw design and actual melt condition.
For special extrusion equipment, oxygen-barrier layer thicknesses or power cable structures, please contact our technical team for processing guidance.
Final processing parameters should be confirmed through production trials under the customer's actual extrusion conditions.
OEM & Customization
- Customized Formulations
- OEM Manufacturing
- Color Matching
- Technical Support
- Small Batch
- Fast Sampling
- Free Samples
FAQ
1. What is B1 LSZH Oxygen Barrier Cable Compound EPC6929?
EPC6929 is a B1-class flame-retardant low smoke zero halogen oxygen barrier compound for power cable constructions.
2. What is the main application of EPC6929?
EPC6929 is used as an oxygen-barrier / internal fire-barrier layer in power cables to help protect the internal insulation and other cable materials.
3. What are the main characteristics of EPC6929?
It features good flame retardancy, low heat release and a high char-forming rate.
4. Why is high char formation important for an oxygen-barrier layer?
A high char-forming rate helps create a protective carbonized layer during fire exposure, supporting thermal shielding of inner cable components.
5. Is EPC6929 an LSZH / HFFR material?
Yes. It is a low smoke zero halogen flame-retardant polyolefin material, and the supplied data lists halogen content at 0 PPM.
6. What oxygen index does EPC6929 provide?
The supplied technical data lists an oxygen index of 43%.
7. What smoke-density data is reported?
The supplied data lists smoke density of 43 by the flaming method and 187 by the nonflaming method.
8. What mechanical properties are reported?
The supplied data lists 8.2 MPa tensile strength and 60% elongation at break.
9. What is the recommended extrusion temperature profile?
Zone 1: 100°C; Zone 2: 130°C; Zone 3: 140°C; Zone 4: 145°C; Zone 5: 150°C; Neck: 155°C; Head: 160°C; Mould: 165°C.
10. Can customized formulations and samples be provided?
Yes. Formulation support, technical guidance and samples can be discussed according to the customer's cable oxygen-barrier structure and fire-performance requirements.
