Item |
Content |
|
Model |
STCR46501 |
|
Product Type |
TPR Injection Molding Compound for Toys |
|
Material Type |
Thermoplastic Rubber (TPR) Injection Molding Material |
|
Main Applications |
Toy Products and Compatible Injection-Molded Components |
|
Flame Performance |
No flammability rating specified in the supplied catalogue |
|
Key Characteristics |
Good Cost Performance, Broad Application Range, Soft Elastomer Properties |
|
Processing |
Thermoplastic Injection Molding |
|
Customization |
Formulation / Color / Technical Support Available |
Product Overview
STCR46501 is a thermoplastic rubber (TPR) injection molding compound developed for toy products. According to the supplied product catalogue, the material offers good cost performance and a broad range of applicable uses, making it suitable for compatible toy and general molded-product applications.
As a TPR toy material and thermoplastic rubber injection molding compound, STCR46501 combines a high melt index of 45 g/10 min with 9.3 MPa tensile strength, 500% elongation at break and Shore A 65 hardness. Its relatively soft hardness and thermoplastic processing characteristics support flexible injection-molded toy components subject to final product evaluation.
Key Features
- TPR Injection Molding Compound
- Designed for Toy Products
- Good Cost Performance
- Broad Application Range
- High Melt Index: 45 g/10 min
- Elongation at Break: 500%
- Soft Shore A Hardness: 65
Technical Data Sheet
|
Test Item |
STCR46501 |
Test Method |
|
Density, g/cm³ |
1.03 |
ASTM D792 |
|
Melt Index, g/10min |
45 |
ASTM D1238 |
|
Tensile Strength, MPa |
9.3 |
ASTM D412 |
|
Elongation at Break, % |
500 |
ASTM D412 |
|
Hardness, Shore A |
65 |
ASTM D2240 |
Recommended Injection Molding Process Temperature
|
Zone |
Zone 1 |
Zone 2 |
Zone 3 |
Zone 4 |
Nozzle |
|
Temperature |
170±10°C |
180±10°C |
190±10°C |
200±10°C |
200±10°C |
STCR46501 is intended for thermoplastic injection molding. The recommended barrel and nozzle temperature profile from the supplied product catalogue is shown below.
The actual processing temperature should be adjusted according to molding conditions, using a flat product surface and freedom from shrinkage as the reference.
For special molds, part structures or processing conditions, please contact our technical team for processing guidance.
Applications
|
Application |
Material Role |
Application Requirements |
Suitability |
|
Toy Product |
TPR Injection Material |
Softness, flexibility, processing efficiency and cost performance |
Recommended |
|
Flexible Toy Component |
Injection-Molded TPR |
High elongation and soft elastomer properties |
Recommended |
|
Soft Molded Component |
TPR Material |
Flexible touch and thermoplastic molding performance |
Application-dependent |
|
General Injection-Molded Product |
TPR Injection Material |
Cost-effective processing and flexible material properties |
Application-dependent |
|
Custom Molded Product |
Customized TPR Material |
Formulation, color and processing matching |
Available |
OEM & Customization
- Customized Formulations
- OEM Manufacturing
- Color Matching
- Technical Support
- Small Batch
- Fast Sampling
- Free Samples
FAQ
1. What is TPR Toy Molding Compound-STCR46501?
STCR46501 is a thermoplastic rubber (TPR) injection molding compound developed for toy products.
2. What applications is STCR46501 designed for?
According to the supplied product catalogue, STCR46501 is intended for toys and has a relatively broad application range.
3. What are the main advantages of STCR46501?
The supplied catalogue highlights good cost performance and a broad range of applicable uses.
4. Is STCR46501 a TPE or TPR material?
The supplied catalogue identifies STCR46501 specifically as a TPR injection molding material, so this page uses TPR as the primary product terminology.
5. What are the main mechanical properties?
Typical values include 9.3 MPa tensile strength, 500% elongation at break and Shore A hardness of 65.
6. What is the density of STCR46501?
The typical density is 1.03 g/cm³ according to ASTM D792.
7. What is the melt index of STCR46501?
The typical melt index is 45 g/10 min according to ASTM D1238.
8. Does STCR46501 have a specified flame-retardant rating?
No flammability rating is specified for STCR46501 in the supplied product catalogue, so no flame-retardant classification is claimed on this page.
9. What is the recommended processing temperature?
Zone 1: 170±10°C; Zone 2: 180±10°C; Zone 3: 190±10°C; Zone 4: 200±10°C; Nozzle: 200±10°C.
10. Can the formulation or color be customized?
Yes. Formulation matching, color matching, technical support and sample evaluation can be provided according to the customer's molded-product and processing requirements.
